Nissan Sentra Service Manual: Wiring diagram

Precaution

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER" The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE- ...

Removal and installation

Power socket Removal and installation Front console power socket Removal Remove the cvt/mt shift selector finisher. Refer to ip-14, "exploded view". Remove cap from the front con ...

Other materials:

Rear power window switch
Removal and Installation REMOVAL Release the pawls using a suitable tool and lift the rear power window switch and finisher as an assembly and remove Disconnect the harness connector from the rear power window switch. Release the pawl (one on each side) using a suitable tool, then se ...

C1105, C1106, C1107, C1108 Wheel sensor
Description When the sensor rotor rotates, the magnetic field changes. It converts the magnetic field changes to current signals (rectangular wave) and transmits them to the ABS actuator and electric unit (control unit). DTC Logic DTC DETECTION LOGIC DTC Display Item Malfunct ...

System description
Component parts Body control system BODY CONTROL SYSTEM : Component Parts Location Bcm (view with instrument panel removed) Combination switch reading system COMBINATION SWITCH READING SYSTEM : Component Parts Location BCM (view with combination meter removed) Combination s ...
