Nissan Sentra Service Manual: Wiring diagram

Power distribution system

Wiring diagram







Basic inspection


Ecu diagnosis information
Bcm, ipdm e/r List of ecu reference ...

Basic inspection
Diagnosis and repair work flow Work flow Overall sequence Detailed flow 1.Get information for symptom Get detailed information from the customer about the symptom (the condition and the ...

Other materials:

BCM  branch line circuit
Diagnosis procedure 1.Check connector Turn the ignition switch off. Disconnect the battery cable from the negative terminal. Check the terminals and connectors of the bcm for damage, bend and loose connection (unit side and connector side). Is the inspection result normal? Yes > ...

Precaution for Harness Repair
Solder the repair part, and wrap it with tape. [Twisted wire fray must be 110 mm (4.33 in) or less.] Do not bypass the repair point with wire. (If it is bypassed, the turnout point cannot be separated and the twisted wire characteristics are lost.) ...

Center console assembly
Exploded View Center console upper finisher Center console side finisher (RH) Center console side finisher (LH) Center console side finisher screw cover (LH/ RH) Center console assembly Center console screw cover (LH/ RH) Center console rear finisher Center console rear fi ...
